| Product Type |
Desktop Fast Ethernet PoE+ Switch |
| Model |
MS106LP |
| Total Ports |
6 × 10/100 Mbps RJ45 |
| PoE+ Ports |
4 × PoE+ (Ports 1–4) |
| Uplink Ports |
2 × 10/100 Mbps |
| PoE Standard |
IEEE 802.3af/at |
| PoE Power per Port |
Up to 30 W |
| Total PoE Budget |
40 W |
| PoE Auto Recovery |
Supported |
| Extend Mode |
Up to 250 m PoE transmission distance* |
| Isolation Mode |
Supported |
| Auto-Negotiation |
Supported |
| Auto MDI/MDIX |
Supported |
| Switching Capacity |
1.2 Gbps |
| MAC Address Table |
2K |
| Jumbo Frame |
2 KB |
| Flow Control |
IEEE 802.3x |
| Forwarding Mode |
Store and Forward |
| Fanless Design |
Yes – Silent Operation |
| Housing |
Durable Metal Casing |
| Installation |
Desktop / Wall Mount |
| Power Supply |
External Power Adapter, 53.5 V / 0.81 A |
| Maximum Power Consumption |
44.8 W with 40 W PoE load |
| Dimensions |
99.8 × 98 × 25 mm |
| Operating Temperature |
0°C to 40°C |
| Storage Temperature |
-40°C to 70°C |
| Operating Humidity |
10%–90% RH, non-condensing |
| Storage Humidity |
5%–95% RH, non-condensing |
| Certifications |
CE, RoHS |
| Package Contents |
MS106LP Switch, Power Adapter, Quick Installation Guide |
