| Product Type |
Line-Interactive UPS |
| Series |
Eaton 5SC |
| Model |
5SC1000I |
| Capacity |
1000 VA / 700 W |
| Technology |
Line-Interactive High Frequency |
| Form Factor |
Tower / Free-Standing |
| Input Voltage |
220 / 230 / 240 V |
| Input Voltage Range |
184–276 V |
| Input Frequency |
45–55 Hz (50 Hz system) / 55–65 Hz (60 Hz system) |
| Input Connection |
1 × IEC C14 |
| Output Voltage |
220 / 230 / 240 V |
| Output Frequency |
50/60 Hz ±0.1% |
| Output Waveform |
Pure Sine Wave |
| Output Power Factor |
0.7 |
| Output Connections |
8 × IEC C13 |
| Automatic Voltage Regulation |
AVR – Booster & Fader |
| Efficiency |
Up to 96% |
| Battery Type |
Maintenance-Free Sealed Lead-Acid |
| Internal Batteries |
2 × 12 V / 9 Ah |
| Battery Management |
Eaton ABM®, Automatic Battery Test & Deep-Discharge Protection |
| Battery Replacement |
User Replaceable |
| Extended Battery |
Not Supported |
| Runtime at 50% Load |
Approx. 13 minutes |
| Runtime at 100% Load |
Approx. 5 minutes |
| Display |
LCD Display |
| Communication Ports |
1 × USB + 1 × RS232 |
| Network Card |
Not Supported |
| Rack Mounting |
Not Supported |
| Auto Shutdown |
Supported |
| Software Compatibility |
Eaton Intelligent Power Protector |
| Noise Level |
<40 dB at 1 m |
| Operating Temperature |
0°C to 35°C |
| Operating Humidity |
0–90% RH, Non-Condensing |
| Dimensions |
210 × 150 × 340 mm |
| Weight |
Approx. 11.1 kg |
| Certifications |
IEC/EN 62040-1, IEC/EN 62040-2, CE, EAC, cTUVus |
| Application |
Servers, Networking Equipment, Storage & IT Infrastructure |
