| Product Type |
8-Port Gigabit Desktop Switch |
| Model |
MS108G |
| Gigabit Ports |
8 × 10/100/1000 Mbps RJ45 |
| Auto-Negotiation |
Supported |
| Auto MDI/MDIX |
Supported |
| Data Rates |
10/100/1000 Mbps Half Duplex; 20/200/2000 Mbps Full Duplex |
| Switching Method |
Store-and-Forward |
| Buffer Capacity |
64 KB |
| Jumbo Frame |
Up to 9 KB* |
| MAC Address Learning |
Supported |
| Standards |
IEEE 802.3 / 802.3u / 802.3x CSMA/CD |
| Green Ethernet |
Power saving up to 82% |
| Management |
Unmanaged / Plug & Play |
| Configuration |
No Configuration Required |
| Cooling |
Fanless / Silent Operation |
| Housing |
Compact Plastic Casing |
| Installation |
Desktop |
| LED Indicators |
Power / Ethernet Link |
| Power Supply |
External Adapter, 9 V / 0.6 A |
| Dimensions |
143.8 × 72.3 × 25 mm* |
| Package Contents |
MS108G, Power Adapter, Quick Installation Guide |
