| Wi-Fi Standard |
Dual-Band Wi-Fi 6 (802.11ax)
|
| Wireless Speed |
Up to 3,000 Mbps combined — 2,402 Mbps on 5 GHz and 574 Mbps on 2.4 GHz |
| 5 GHz Band |
Up to 2,402 Mbps, supporting 160 MHz channels
|
| 2.4 GHz Band |
Up to 574 Mbps
|
| Wireless Coverage |
Up to 650 m² (7,000 ft²)
|
| Device Capacity |
Supports 150+ connected devices simultaneously |
| Wireless Technologies |
OFDMA, MU-MIMO, and 1024-QAM |
| Ethernet Ports |
3 × Gigabit Ethernet ports per unit |
| WAN/LAN |
Automatic WAN/LAN detection
|
| Seamless Roaming |
Single unified Wi-Fi network with automatic switching to the strongest Mesh unit |
| Network Management |
Easy setup, configuration, and monitoring through the Mercusys App
|
